Insulated Glass

Description:

By combining Low-E coatings, standard and high performance tinted glass, reflective coatings, silk-screened patterns, laminated glass products and more, a wide variety of insulating glass configurations are available to satisfy a wide range of performance and aesthetic requirements. Insulated glass units can be fabricated to meet state energy and safety codes, sound control and seismic requirements, impact, bullet, hurricane and blast resistance requirements. Insulated glass units can be designed to reduce heat loss and solar heat gain entering the building, with a minimal reduction of visible light transmittance.

Insulated glass units are fabricated according to project specifications. Insulated glass units can be constructed using a large variety of glass products to achieve desired aesthetics, meet design criteria, safety codes and/or to improve solar control and thermal performance.

Glass options include clear, low iron, Low-E’s, standard or high performance (spectrally selective) tints, reflective, silk-screened, spandrel, laminated, decorative and wired glass.

Specification:

=Thickness: 5+9A+5mm; 6+12A+6mm; 6+16A+6mm; 8+12A+8mm; 8+16A+8mm; etc

=Max Size: 3300mm x 10000mm (except for manual production)

=Min Size: 180mm x 350mm

=Air or argon spacer gap:6mm, 9mm, 12mm, 15mm, 16mm etc

=Glass Option: Annealed Float glass, Low-E Glass, Tinted Glass, Reflective Glass, Laminated Glass, Tempered Glass, Silk screened Glass etc

=Glass Color: Clear, Ultra Clear( low iron), light blue, Ford blue, dark blue, ocean blue,  light gray, blue gray, light green, gold, bronze etc.

=Standard: GB/T 11944  ASTM C1172  EN1279  JIS R3205  AS/NZS4666

Application:

Insulating Glass (IG) units are used in essentially all exterior building applications, including vertical glazing, sloped glazing, overhead glazing and skylights, and also in both vision and spandrel (non-vision) areas.

=Skylight, storefront, office indoor partition;

=Shower door, sliding door, swinging door;

=Pool fence, balustrade, balcony;

=Dining table, glass furniture;

=Window, curtain wall, stairs, glass wall, glass railing;

=Splash back, shower screen, glass floor.
